1.9/3.3kV CU Multi Core SWA PVC Cable BS 5467/IEC 60502-1

Application

When you are managing power networks and power distribution project, this MV cable is a good option, which is designed for both main power distribution and auxiliary control circuits, these cables are designed for highly versatile deployment across power networks. They are fully rated for indoor and outdoor routing, installation within cable ducts, and direct underground burial in free-draining soil conditions.

If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!

Structure

Conductor

Class 2 sectoral shaped stranded copper

Insulation

XLPE (Cross-Linked Polyethylene)

Separator

Polyester Tape

Filler

PVC (Polyvinyl Chloride)

Armour

SWA (Galvanised steel wire armour)

Outer Sheath

PVC (Polyvinyl Chloride)

Color

Customized as per standards

Technical data

Voltage Rating

1.9/3.3kV

Temperature Rating

Maximum Operating: +90ºC

Maximum Short-Circuit: +250°C

Minimum Bending Radius

12 x overall diameter

Standards

BS 6724, EN 60228

Flame retardant to IEC/EN 60332-1

UV Resistant

Certificates

We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
