RG Coaxial Cable

Application

High-quality 50 or 75 Ohm RG-type coaxial cables (RG6, RG11, RG58, RG59, RG179, RG213) are designed ideally for low-power video, standard video, and broadband signal transmission.

If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!

Structure

Conductor

RG6 / RG11 / RG59: CCS (Copper Clad Steel)

RG58 / RG179: TCW (Tinned Copper Wire)

RG59 Shotgun: CCA (Copper Clad Aluminium)

RG213: Plain Copper

Insulation

RG6 / RG11 / RG 179: FPE (Foam Skin Polyethylene)

RG58 / RG59 / RG59 Shotgun / RG213: PE (Polyethylene)

Shield

RG6: Aluminium foil

Braiding

RG6 / RG59 / RG59 Shotgun: CCA (Copper Clad Aluminium)

RG58: TCWB (Tinned Copper Wire Braid)

Sheath

RG6 / RG11 / RG58 / RG59 / RG179 / RG213: PVC (Polyvinyl Chloride)

RG59 Shotgun / RG213 LSZH: LSZH (Low Smoke Zero Halogen)

Color

Identification as per international standards

Technical data

Voltage Rating

30V

Operating Temperature:

-20°C to +75ºC

Standards

IEC/EN 60228,

Flame Retardant according to BS EN 60332-1-2

Low Smoke Halogen Free according to IEC/EN 60754-1/2, IEC/EN 61034-1/2

Certificates

We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
