Flexible Copper Screened Mining Rubber Cable

Application

This unshielded cable is designed as flexible trailing cables, larger sizes power heavy machinery like draglines, while smaller sizes supply hand-held tools and drills.

If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!

Structure

Conductor

Tinned annealed copper wires

Separator

1.1kV: Paper separator

For other nominal voltages semi-conductive tape+ thermosetting compound over conductors

Insulation

EPR (Ethylene Propylene Rubber)

Insulation Screen

1.1kV: Synthetic tape

From 3.3kV: Semi-conductive thermosetting compound

Screen

Tinned copper/polyamide braid

Sheath

HD-PCP (Heavy Duty Polychloroprene) - extra heavy duty, oil resistant and flame retardant

Technical data

Voltage Rating

1.1~22kV

Temperature Rating

-25°C to +90°C

Standards

Water resistant

Flame retardant, UV, sunlight, ozone and oil resistant

Certificates

We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
