Mineral Insulated Fire-Resistant Cable

Application

This unshielded cable is designed to transmit high currents to welding tools, this highly flexible cable thrives in rough environments. It is ideal for manual and automated spot welding systems across automotive, shipbuilding, and machine tool assembly lines.

If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!

Structure

Conductor

16mm² to 95mm2 : Class 6 extra flexible tinned copper conductor

120mm² and above: Class 5 flexible tinned copper conductor

Separator

PET (Polyester Tape)

Insulation

EPR (Ethylene Propylene Rubber)

Sheath

HOFR (Heat and Oil Resistant and Flame Retardant)

Technical data

Voltage Rating

100V (450V for non-welding applications if suitably protected from mechanical damage)

Temperature Rating

Flexed: -20ºC to +85°C

Minimum Bending Radius

Flexed: 6 x overall diameter

Standards

BS638 Part 4 (withdrawn), EN 60228

Flame Retardant according to IEC/EN 60332-1-2

Certificates

We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards

Production
