Voltage:300/500V
Conductor: Stranded bare copper wires (AWG24/7)
Insulation: FPE (Foam Skin Polyethylene)
Separator Tape: PET (Polyester)
Pair Shield: Al/PET (Aluminium Polyester Tape)
Braid:TCWB (Tinned Copper Wire Braid) 90% coverage
Sheath: PUR (Polyurethane)
Main Application: flexible and durable PUR cables are designed to connect machinery and production lines, used in both indoor and outdoor applications. PUR cables are mostly used in oil, mining and chemicals industries with high requirement on extreme industrial environments such as abrasion and high mechanical stress.
When you are managing to connect machinery and production lines, flexible and extreme durable PUR cables are the best choice. They are designed to be used in both indoor and outdoor applications, especially in oil, mining and chemicals industry with high requirement on extreme industrial environments such as abrasion and high mechanical stress.
If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!
Conductor
Stranded bare copper wires (AWG24/7)
Insulation
FPE (Foam Skin Polyethylene)
Separator
Tape PET (Polyester)
Pair Shield
Al/PET (Aluminium Polyester Tape
Braid
TCWB (Tinned Copper Wire Braid) 90% coverage
Sheath
PUR (Polyurethane)
Color
Identification as per international standards
Operating Temperature:
Fixed: -40°C to +80°C
Flexed: -20°C to +70°C
Minimum Bending Radius
Fixed: 8 x overall diameter
Flexed: 12 x overall diameter
IEC 61156-6/BS EN 60811-404
We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
