Voltage:300/500V
Conductor: Class 5 Flexible Copper Conductor
Insulation: Cross linked EPR (Ethylene Propylene Rubber)
Outer Sheath: PUR (Polyurethane)
Main Application: this EPR insulated PUR cable is designed to be used specially for indoor light-duty applicabces such as kitchens and offices, where there is need lower mechanical stress. Please be noted it has limited temporary outdoor usage.
When you are managing to use PUR cable for indoor, light-duty appliance and office equipments under lower mechanical stress, this kind of EPR insulated PUR cable is a good option. It is designed to be used specially for indoor light-duty applicabces such as kitchens and offices, where there is need lower mechanical stress. Please be noted it has limited temporary outdoor usage.
If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!
Conductor
Class 5 Flexible Copper Conductor
Insulation
Cross linked EPR (Ethylene Propylene Rubber)
Outer Sheath
PUR (Polyurethane)
Color
Identification as per international standards
Voltage Rating
300/500V
Operating Temperature
Operating: -40ºC to +90ºC
Maximum Short Circuit Temperature: 250ºC (Max. 5 seconds)
Minimum Bending Radius
5 x overall diameter
EN 50363-1, EN 50363-10-2, EN 50525-2-21, EN 6022
We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
