SAA Certificated Cable TCWB Screened TPU Cable

Application

This unshielded cable is designed for automotive electric powertrain.

If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!

Structure

Conductor

Class 6 fine flexible stranded Copper

Insulation

SiR (Silicon rubber)

Color

Identification as per international standards

Technical data

Voltage Rating

0.6/1kV

Test Voltage

spark test: 8kV 5

minutes: 5kV

Operating Temperature:

Operating temperature: -40ºC to +180ºC 3000 (hours)

Short term ageing: +205 °C 240 (hours)

Minimum Bending Radius

Static installation: 2 x overall diameter

Dynamic Installation: 4 x overall diameter

Standards

DIN EN 13602

Certificates

We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
