Voltage:450/750V
Conductor: Class 5 Flexible Copper Conductor
Insulation: Cross linked EPR (Ethylene Propylene Rubber)
Outer Sheath: PUR (Polyurethane)
Main Application: this EPR insulated PUR cable is designed to be used specially for heavy-duty industrial, agricultural and construction equipments, which require to bear medium mechanical stress. It is ideal option for construction sites, agricultural machinery and damp enviroments.
When you are managing to use PUR cable for heavy-duty industrial, agricultural and construction equipments, this kind of EPR insulated PUR cable is a good option. This type of EPR insulated PUR cable is designed to be used specially for heavy-duty industrial, agricultural and construction equipments, which require to bear medium mechanical stress. It is ideal option for construction sites, agricultural machinery and damp enviroments.
If you need specification beyond our standard range, please contact with us by email , tailored quotation will be in your inbox!
Conductor
Class 5 Flexible Copper Conductor
Insulation
Cross linked EPR (Ethylene Propylene Rubber)
Outer Sheath
PUR (Polyurethane)
Color
Identification as per international standards
Voltage Rating
450/750V
Test Voltage
2.5kV
Operating Temperature
Operating: -40ºC to +90ºC
Maximum Short Circuit Temperature: 250ºC (Max. 5 seconds)
Minimum Bending Radius
5 x overall diameter
EN 50363-1, EN 50363-10-2, EN 50525-2-21, EN 6022
We have certificates such as KEMA/CE/TUV/UL/GOST/EAC/RoHS/CNAS under international standards
